Product Properties

  1. Excellent flame retardant properties, low flammability the limiting oxygen index(LOI) is from 29% to 40%, start to carbonise and decompose above 500°C

  2. Excellent high temperature resistance, It is able to work for a long period of time under acid base from -200°C to 250°C, 70% strength of threads remains after being in 290°C for 1000 hours

  3. Chemical stability, has a high resistance to weak acid, weak base and the majority of organic solvents

  4. Good textile properties, high resistance to breakage and its high break elongation ratio guaranteed the end product with high intensity, good product longevity, and better tolerance to injection

  5. No Melt Drip properties, flame resistant with self-extinguish nature and non-melt drip characteristic.

  6. High Strength and low weight, excellent strength-to-weight ratio

  7. High modulus

  8. High dimensional stability: very low creep, small negative thermal expansion coefficient

  9. Excellent thermal stability: usable across a wide temperature range, no melting point, high heat stability, low heat conductivity

  10. High cut resistance

  11. Electrically non-conductive

  12. Long, well-defined lifetime



Technical Data

Material:

100% para aramid, kevlar Yarn Count: 20S2
Pattern:  Dyed Weight : 1kg/cone
Yarn Type:
Spun CV Breaking Strength: 5.35%
Breaking Strength Tenacity: 73.77cN/tex Breaking Elongation%: 5%
Breaking Strength(cN): 4283 Twist 26.63T/10cm
Technical Data

Material:

100% paraaramid
Pattern:  Dyed
Yarn Type: Spun
Breaking Strength Tenacity: 73.77cN/tex
Breaking Strength(cN): 4283
Yarn Count: 20S2
Weight : 1kg/cone
CV Breaking Strength: 5.35%
Breaking Elongation%: 5%
Twist: 26.63T/10cm


Product Description

       Para-aramid spun yarn is suitable for use across a wide range of challenging applications and industries, from ballistic protection to heat and cut protection, and from oil and gas to the automotive and telecommunications industries, from civilian products to military products.



Product Details
Content: 100% para aramid
Specification : 20s/2, 1000g/cone, other yarn sizes 36s/3 20s/3, 30s/3, 20s/1, 20s/2 etc. are available and customized thread size is acceptable
Color: Yellow, Red, Cream, Black, Grey, Blue, Orange, Khaki etc., Customized color is available
Use:

Sewing, Cross Stitch, Embroidey,Hand Knitting, Weaving

Feature:

Radiation resistance, mechanical stability, electrical insulation, Low Shrinkage, High Temperature Resistant, Chemical-Resistant, Abrasion-Resistant, High Tenacity, flame retardant, self-extinguishing, high cut resistance, flame retardant

MOQ: 10 kilograms
Meet standard : AATCC/ASTM, EN, ISO, GB, AS
Application : Used for protective clothing, gloves, PPE products, firefighter uniform, flame retardant curtains, fire blanket, anti-cut gloves, bulletproof
